- Description
1.25Gbps CWDM SFP Optical Transceiver, 120km Reach
Features
Data-rate of 1.25Gbps operation
9 CWDM DFB wavelengths laser and APD photodetector for 120km transmission
Compliant with SFP MSA and SFF-8472 with duplex LC receptacle
Digital Diagnostic Monitoring:Internal Calibrationor External Calibration
Compatible with SONET OC-24-LR-1
Compatible with RoHS
+3.3V single power supply
Operating case temperature:Standard : : 0°C to 70°C(Standard), -40°C to 85°C (Industrial)
ApplicationsGigabit Ethernet
Fiber Channel
Switch to Switch interface
Switched backplane applications
Router/Server interface
Other optical transmission systems
DescriptionThe SFP transceivers are high performance, cost effective modules supporting data-rate of 1.25Gbps and 120km transmission distance with SMF.
The transceiver consists of three sections: an uncooled CWDM DFB laser transmitter, an APD photodiode integrated with a trans-impedance preamplifier (TIA) and MCU control unit. All modules satisfy class I laser safety requirements.
The transceivers are compatible with SFP Multi-Source Agreement (MSA) and SFF-8472. For further information, please refer to SFP MSA.
Table -λC Wavelength Guide
λC Wavelength Guide
Code
λC
λC
Code
λC
Code
λC
Code
35
1350nm
45
1450nm
55
1550nm
27
1270nm
37
1370nm
47
1470nm
57
1570nm
29
1290nm
39
1390nm
49
1490nm
59
1590nm
31
1310nm
41
1410nm
51
1510nm
61
1610nm
33
1330nm
43
1430nm
53
1530nm
